High Charts Implementation in React

Highcharts is a powerful charting library that allows developers to add interactive and customizable charts to web applications. This article demonstrates how to implement Highcharts in a React application, focusing on creating Pie Charts and Bar Charts.

Prerequisites

To follow along, ensure you have the following:

Node.js and npm/yarn installed on your system. Basic knowledge of React.

Setting Up the Project

First, create a new React project using create-react-app or your preferred setup.

npx create-react-app highcharts-example
cd highcharts-example

Install Highcharts and the official React wrapper for Highcharts:

npm install highcharts react-highcharts

Adding a Pie Chart

Step 1: Basic Configuration

Create a new component named PieChart.js:

touch src/components/PieChart.js

Edit the file and set up the pie chart:

import React from "react";
import HighchartsReact from "highcharts-react-official";
import Highcharts from "highcharts";

const PieChart = () => {
    const options = {
        chart: {
            type: "pie"
        },
        title: {
            text: "Browser Market Share"
        },
        series: [
            {
                name: "Share",
                data: [
                    { name: "Chrome", y: 63.59 },
                    { name: "Safari", y: 19.2 },
                    { name: "Firefox", y: 4.2 },
                    { name: "Edge", y: 3.4 },
                    { name: "Other", y: 9.61 }
                ]
            }
        ]
    };

    return <HighchartsReact highcharts={Highcharts} options={options} />;
};

export default PieChart;

Step 2: Rendering the Component Update App.js to include the PieChart component:

import React from "react";
import PieChart from "./components/PieChart";

function App() {
    return (
        <div>
            <h1>Highcharts in React</h1>
            <PieChart />
        </div>
    );
}

export default App;

Run the application:

npm start

You should see an interactive pie chart displaying browser market shares.

Adding a Bar Chart

Step 1: Basic Configuration Create another component named BarChart.js:

touch src/components/BarChart.js

Edit the file and set up the bar chart:

import React from "react";
import HighchartsReact from "highcharts-react-official";
import Highcharts from "highcharts";

const BarChart = () => {
    const options = {
        chart: {
            type: "bar"
        },
        title: {
            text: "Monthly Sales Data"
        },
        xAxis: {
            categories: ["January", "February", "March", "April", "May"]
        },
        yAxis: {
            title: {
                text: "Sales (in USD)"
            }
        },
        series: [
            {
                name: "Sales",
                data: [5000, 7000, 8000, 6000, 9000]
            }
        ]
    };

    return <HighchartsReact highcharts={Highcharts} options={options} />;
};

export default BarChart;

Step 2: Rendering the Component Update App.js to include the BarChart component:

import React from "react";
import PieChart from "./components/PieChart";
import BarChart from "./components/BarChart";

function App() {
    return (
        <div>
            <h1>Highcharts in React</h1>
            <PieChart />
            <BarChart />
        </div>
    );
}

export default App;

Styling and Customization

Highcharts is highly customizable. You can:

Change Colors: Modify the colors array in the options object. Add Tooltips: Customize tooltips with the tooltip property. Customize Legends: Adjust legends using the legend property.

For example, adding a custom tooltip in the bar chart:

tooltip: {
    formatter: function () {
        return `<b>${this.x}</b>: $${this.y}`;
    }
}

Conclusion

Highcharts makes it straightforward to create beautiful, interactive charts in React. This article demonstrated how to implement Pie Charts and Bar Charts, which are just a starting point. Explore the vast customization options Highcharts offers to tailor charts to your application's needs.

Happy coding!
